Chapter 6 Operating Instructions

CLV490 Bar Code Scanner

Operation

Note At a scanning frequency of 1,000 Hz, the typical response time for focus adjustment is

20 ms, or 30 ms if the entire range (between min. and max. focus position) is traversed.

The CLV490 does not switch over the focus until the defined timeout has elapsed and the

new focus position exceeds the parameterized hysteresis value relative to the old focus

position. If the new focus position is within the hysteresis, the CLV490 does not switch over

the focus.

Depth-of-field optimization with respect to the object and the purpose of depth-of-field

optimization are described in Chapter 3.2.1 Autofocus function, Page 3-7.

2. Configure autofocus Additionally for autofocus mode "Differential background“ ’

and „Differential background and tracking“:

Ö AUTOFOCUS SPACE section

– Right edge of conveyor (Y 1)

– Left edge of conveyor (Y 2)

– Level of conveyor (Z 1)

– Maximum scanning height (Z 2)

Ö AUTOFOCUS OPTIMIZATION PARAMETERS button

Ö DELAY OF FOCUS CHANGE section

–Timeout

–Hysteresis

Ö DEPTH OF FIELD OPTIMIZATION section

– Offset at minimum

– Offset at maximum

Ö "Distance measurement" section (default setting)

– active

– Source of distance information: internal/external

– Smooth filter: active, length 3

3. Teach-in background

(optional)

For autofocus mode "Differential background“ and „Differential

background and tracking“:

Ö Menu CLV490

Ö DEVICE FUNCTIONS

Ö Background

–Teach-in

Check taught-in background:

Ö READING CONFIGURATION tab

Ö AUTOFOCUS section

Ö SHOW BACKGROUND

button

Displaying online the actual background profile with focus level

points:

Ö Menu CLV490

Ö BACKGROUND ANALYSIS

– Analysis: Autofocus

4. Select focus position

switchover (refered to the

start of the reading interval)

Ö READING CONFIGURATION tab

Ö FOCUS CONTROL section

Ö INPUTS/SERIAL/AUTOFOCUS

– immediate or synchronous (default setting) or

–latched

2) The CLV490 displays the taught-in background with the internal correction of 100 mm (3.9 in) but not the parameterized

limits of the autofocus space.

Action Settings in CLV-Setup

Table 6-6: Guide: Configuring the autofocus function (part 1) (contd.)
