Chapter 8 Operating Instructions

CLV490 Bar Code Scanner

Troubleshooting

on the auxiliary interface. The reading interval must be terminated by resetting the trig-

ger signal. The laser diode is activated again by the next reading trigger.

8.3 Error messages

The CLV490 outputs coded error message (number combinations) via the auxiliary inter-

face only. Table 8-1 contains a list of the messages.

Displaying messages:

To display the messages on the PC, proceed as follows in CLV-Setup:

¾ Click in the toolbar.

The Terminal Emulator is launched.

CLV-Setup logs the error messages automatically in a file (sys_msg.log).

8.3.1 CLV490 without external parameter memory

Message Meaning Possible cause Remedy

"CLV SYS-Failure: xxx" The CLV490 has diagnosed a

system error.

The "Device Ready" LED does

not light up or extinguishes.

The system is restarted.

Error key:

)

011 Data error (RAM)

012 Address error (RAM)

013 RAM to small

051 Speed out of tolerance

(mirror wheel)

061 Mirror interval out of

tolerance

071 Error: laser shutter

091 to 095 Error: focus control

101 to 118 Error: external parameter

memory

130 Amplifier error

131 Background profile invalid

132 Center reading angle

RA 50 implausible

133 Brightness overflow

201 to 215 DSP error

If the error occurs again after

the CLV490 is restarted, con-

tact the SICK Service depart-

ment.

1) Deactivate the CAN interface to suppress error numbers above 300 (not relevant in stand-alone mode).

To do so, upload the parameter set from the CLV490 using CLV-Setup, choose the CAN I

NTERFACE tab and deactivate the function in the CAN INTERFACE FUNCTION section.

Download the parameter set to the CLV490!

Table 8-1: Error messages output on the auxiliary interface
