10.6.5 Functions

The "CLV-Setup" program (from version V 4.0) features the following functions to carry out:

• Uploading the default parameter set from the database of CLV-Setup

• Automatic communication attempt with the CLV490 when the program is started

• Automatic software compatibility check in the CLV490

• Uploading and displaying parameter set stored in the CLV490

• Changing the parameter/parameter values on the tabs

• Downloading the changes to the parameter set in the CLV490

• Saving the changes to the parameter set as a configuration file "*.scl"

• CLV Assistant for simplified parameterization (not for CLV490)

• Printing the configuration files

• Exporting the configuration files in RTF format

• Exporting the command strings contained in the profile bar codes in ASCII format

• Printing the parameter set in the form of profile bar codes (not for CLV490)

• Online access to the CLV490 via a Terminal Emulator (select operating mode, start

operating functions, log file for communication between the CLV490 and CLV-Setup,

extended Terminal mode, e. g. for displaying CLV490 messages)

• AutoBaud Detect for automatic communication setup with the CLV490

• Selecting the COM port of the PC for adapting the data transfer parameters

• Monitoring the data communication of the CLV host interface

• Selecting language setting

• Selecting units of measure

• Displaying the last 10 configuration files that were processed

• Saving the CLV490 type that was selected last

• Automatic storage confirmation prompt when changes are made to the configuration file

• Wizards for individual functions

• Clearing the optional CMC400 parameter memory in the CDB/CDM Connection

Module

• CLV490 only: Aligment check to calculate the required setting for angles

• CLV490 only: Background analysis

• CLV490 only: I/O monitoring

• Setting switches for starting the program (in the "CLVmain.ini" file)

• Hot keys [F keys] for important functions (using the program without a mouse)

• Starting program with SCL file as argument

• Macro player for recording and playing a macro file

• Context-sensitive help via the [F1] key

10.6.6 Hot keys

[F1] Start "CLV-Setup Help“ online

[F2] Open dialog box to execute device functions

[F3] Upload complete set of parameters from CLV490

[F4] Download complete set of parameters to CLV490

[F5] Open configuration file

[F6] Save configuration file

Light Source	LED, visible red light (660 nm)
Protection Class	IP65
Typical Scan Rate	500 scans/s
Ambient Operating Temperature	0 °C ... +50 °C
Power Supply	10 V DC ... 30 V DC
