Operating Instructions Chapter 5

CLV490 Bar Code Scanner

Electrical installation

For connecting the switching outputs via the CDB420 or CDM490 Connection Module, see

the Operating Instructions for the "CDB420 Connection Module" (no. 8010001, German/

English) respectively the Operating Instructions for the "CDM490 Connection Module"

(no. 8010005, German/English).

Tip

The output function, pulse duration (timer), and polarity of the signals can be changed on

the D

EVICE CONFIGURATION tab in the "CLV-Setup" program.

¾ Click the R

ESULT OUTPUTS Parameter button.

Enter the values in the dialog box displayed.

Perform a download to the CLV490.

Recommendation ¾ To check the switching functions using a high-impedance digital voltmeter, connect a

load to the outputs to prevent incorrect voltage values/switching statuses from being

displayed.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

Light Source

LED, visible red light (660 nm)

Protection Class

IP65

Typical Scan Rate

500 scans/s

Ambient Operating Temperature

0 °C ... +50 °C

Power Supply

10 V DC ... 30 V DC
