Chapter 6 Operating Instructions
DME5000
88 © SICK AG • Germany • Subject to change without notice 8009813/ZJV1/2017-05
Information field 1 (example)
– 65 dB Reception level: Current signal damping
Ver. 1.0 Software version
3.3.3.1 Submenu item (see Menu overview), parameter changes not possible.
3.3.3.1 ! "!": Code entered correctly: Parameter changes possible.
3.3.3.1 ? "?": Entered parameter is invalid, previous valid parameter remains
saved.
Cause: e.g. lower switching limit > upper switching limit.
Remedy: Correct parameters.
Information field 2 (example)
+ 010.000 m Current distance value, displayed in measuring mode.
Code Menu items and parameters are displayed here. "Code" appears
by pressing of
.
Service Flashing Service indication signals a hardware defect or
over-/undertemperature.
Keys
Guides through the menu structure, code, parameter input, parameter
storage.
Leaving a submenu item.
Selection of menu items, input of figures
