SICK GM32 Technical Information

CAN Connection
GM32 · Technical information · 8011923 · V1.4 · © SICK AG 25
Subject to change without notice
3.3.1 Settings in GM32
Menu: Parameter/Device Parameter (  p. 34, §4.2.3.1)
Valid for the CAN interface to SCU.
● Address for SCU interface: 17 (preset for 1 device)
(range available for further devices: 16, 18, .. 31)
● Baudrate: 125 (preset)
3.3.2 Settings in the SCU
● Set in the SCU ( Operating Instructions of the SCU):
– Baudrate: Corresponding to the GM32 setting
–CAN: 1 (always)
