Operation (Specialist Menus)
GM32 · Technical information · 8011923 · V1.4 · © SICK AG 31
Subject to change without notice
4.2 Menu tree (in SOPAS ET)
GM32 Reference Level
1
1
A = user level “Authorized user”.
S = user level “Service”.
----
Measured values
p. 33, §4.2.2 A
¦ ¦--
Bargraph measured values
p. 33, §4.2.2.1 A
----
Parameters
p. 34, §4.2.3 A
¦ ¦--
Device parameters
p. 34, §4.2.3.1 A
¦ ¦--
Spectrometer
p. 35, §4.2.3.2 S
¦ ¦--
Spectral analysis ---
2
2
Not described in this Manual. Please contact SICK Customer Service.
S
¦ ¦--
Coefficients
p. 35, §4.2.3.3 A
¦ ¦--
Coefficients boxmeasuring
p. 36, §4.2.3.4 S
¦ ¦--
Check cycle ---
2
S
¦ ¦--
Adjustment sensor
p. 36, §4.2.3.5 S
¦ ¦--
Mirror tracking ---
2
S
¦ ¦--
Data storage ---
2
S
¦ ¦--
Logbook configuration
p. 37, §4.2.3.6 S
¦ ¦--
Analog output
p. 38, §4.2.3.7 A
¦ ¦--
Analog input
p. 38, §4.2.3.8 A
¦ ¦--
Digital input
p. 39, §4.2.3.9 A
¦ ¦--
Digital output
p. 39, §4.2.3.10 A
¦ ¦--
Hardware Map
p. 41, §4.2.3.11 S
¦
'--
Options ---
2
S
----
Adjustment
p. 42, §4.2.4 A
¦ ¦--
Alignment
p. 42, §4.2.4.1 A
¦ ¦--
Zero adjust
p. 43, §4.2.4.2 S
¦
'--
Boxmeasuring
p. 44, §4.2.4.3 A
----
Diagnosis
p. 45, §4.2.5 A
¦ ¦--
Device information
p. 45, §4.2.5.1 A
¦ ¦--
Software versions ---
2
S
¦ ¦--
Logbook
p. 45, §4.2.5.2 A
¦ ¦--
Check cycle
p. 47, §4.2.5.3 A
¦ ¦--
Check values Service ---
2
S
¦
'--
Sensor values
p. 47, §4.2.5.4 A
