Operation (Specialist Menus)
GM32 · Technical information · 8011923 · V1.4 · © SICK AG 45
Subject to change without notice
4.2.5 Diagnosis
4.2.5.1 Device information
Menu: GM32/Diagnosis/Device information
4.2.5.2 Logbook
Menu: GM32/Diagnosis/Logbook
Max. number of entries: 6000.
(Representation: Uncompressed data storage)
Designation Remark
Fill level of logbook in %.
When the characters are red: The logbook is full.
Warning mode: Further entries are not accepted.
Ring buffer mode: Oldest entries are overwritten.
Data storage:
Symbol not crossed out: Compressed.
Symbol crossed out: Uncompressed.
Significance and default:
 p. 37, §4.2.3.6
Ring buffer mode
Warning mode
Significance and default:
 p. 37, §4.2.3.6
Entries Number of entries of selected filter.
