SICK miniTwin4 User Manual

ca. 21
32
6 15
Figure 68: Dimensional drawing of C-Fix bracket (mm), part no. 2045843 (set)
C-Fix-Flex bracket (rotatable)
ca. 40,5
ca. 40,5
27,1
11,8
Figure 69: Dimensional drawing of C-Fix-Flex bracket, rotatable (mm), part no. 2056598
15.2 Connectivity
System connection
T
able 36: Single system system plug, 1 connecting cable
Part Part number
160 mm with male connector M12×4 + FE 2046447
350 mm with male connector M12×4 + FE 2046449
700 mm with male connector M12×4 + FE 2046451
10 m, stripped 2051290
