SICK miniTwin4 User Manual

5.3 Mounting the system plug
Overview
T
he safety light curtain is already connected to the device connection using a system
plug:
•
For single systems: system plug with system connection
•
For cascaded systems: system plug with system connection and extension connec‐
tion.
!
"
§
Figure 33: System plug with system connection
!
System plug
"
System connection
§
Device connection
!
$
"
§
Figure 34: System plug with system connection and extension connection
!
Extension connection
"
System plug
§
System connection
$
Device connection
MOUNTING 5
8012624/10OM/2018-08-09 | SICK O P E R A T I N G I N S T R U C T I O N S | miniTwin4
45
Subject to change without notice
