SICK miniTwin4 User Manual

14 Ordering information
14.1 Scope of delivery
Scope of delivery of twin stick
•
T
win stick
•
System plug
•
Test rod with diameter corresponding to the resolution of the safety light curtain
•
Bracket: Depending on type selected (C-Fix and L-Fix or O-Fix). The C-Fix-Flex align‐
ment bracket is available as an accessory.
•
Safety note
•
Installation Instructions
•
Operating instructions for download: www.sick.com
14.2 Ordering information miniTwin4
Single device or cascade end devices
T
able 24: Ordering information for 14 mm resolution
Protective field height in mm Type code Part number
120 C4MT-01214ABB03BE0 1207094
180 C4MT-01814ABB03BE0 1207097
240 C4MT-02414ABB03DE0 1207098
300 C4MT-03014ABB03DE0 1207099
360 C4MT-03614ABB03DE0 1207100
420 C4MT-04214ABB03DE0 1207101
480 C4MT-04814ABB03DE0 1207102
540 C4MT-05414ABB03DE0 1207103
600 C4MT-06014ABB03FE0 1207104
660 C4MT-06614ABB03FE0 1207105
720 C4MT-07214ABB03FE0 1207106
780 C4MT-07814ABB03FE0 1207107
840 C4MT-08414ABB03FE0 1207108
900 C4MT-09014ABB03FE0 1207109
960 C4MT-09614ABB03FE0 1207110
1020 C4MT-10214ABB03FE0 1207111
1080 C4MT-10814ABB03FE0 1207112
1140 C4MT-11414ABB03FE0 1207113
1200 C4MT-12014ABB03FE0 1207114
Table 25: Ordering information for 24 mm resolution
Protective field height in mm Type code Part number
120 C4MT-01224ABB03BE0 1207222
180 C4MT-01824ABB03BE0 1207223
240 C4MT-02424ABB03DE0 1207224
300 C4MT-03024ABB03DE0 1207225
360 C4MT-03624ABB03DE0 1207227
420 C4MT-04224ABB03DE0 1207228
480 C4MT-04824ABB03DE0 1207229
ORDERING INFORMATION 14
8012624/10OM/2018-08-09 | SICK O P E R A T I N G I N S T R U C T I O N S | miniTwin4
95
Subject to change without notice
