SICK miniTwin4 User Manual

Protective field height in mm Type code Part number
480 C4MT-04824ABB03DB0 1207178
540 C4MT-05424ABB03DB0 1207323
600 C4MT-06024ABB03FB0 1207324
660 C4MT-06624ABB03FB0 1207325
720 C4MT-07224ABB03FB0 1207326
780 C4MT-07824ABB03FB0 1207327
840 C4MT-08424ABB03FB0 1207328
900 C4MT-09024ABB03FB0 1207329
960 C4MT-09624ABB03FB0 1207330
1020 C4MT-10224ABB03FB0 1207331
1080 C4MT-10824ABB03FB0 1207332
1140 C4MT-11424ABB03FB0 1207180
1200 C4MT-12024ABB03FB0 1207333
Table 32: Ordering information for 34 mm resolution
Protective field height in mm Type code Part number
120 C4MT-01234ABB03BB0 1207334
180 C4MT-01834ABB03BB0 1207335
240 C4MT-02434ABB03DB0 1207336
300 C4MT-03034ABB03DB0 1207337
360 C4MT-03634ABB03DB0 1207338
420 C4MT-04234ABB03DB0 1207339
480 C4MT-04834ABB03DB0 1207340
540 C4MT-05434ABB03DB0 1207341
600 C4MT-06034ABB03FB0 1207342
660 C4MT-06634ABB03FB0 1207343
720 C4MT-07234ABB03FB0 1207344
780 C4MT-07834ABB03FB0 1207345
840 C4MT-08434ABB03FB0 1207346
900 C4MT-09034ABB03FB0 1207347
960 C4MT-09634ABB03FB0 1207348
1020 C4MT-10234ABB03FB0 1207349
1080 C4MT-10834ABB03FB0 1207350
1140 C4MT-11434ABB03FB0 1207351
1200 C4MT-12034ABB03FB0 1207169
14.3 Weld spark guard
Overview
NOTE
•
2 addit
ional front screens (weld spark guard) are supplied per part number.
•
An additional front screen reduces the scanning range of the system by 7.5%. If 2
opposing twin sticks use an additional front screen, this reduces the scanning
range by 15%.
ORDERING INFORMATION 14
8012624/10OM/2018-08-09 | SICK O P E R A T I N G I N S T R U C T I O N S | miniTwin4
99
Subject to change without notice
