SICK miniTwin4 User Manual

Power supply units
T
able 42: Ordering information for power supply
Part Type code Part number
Output 24 V DC, 50 W (2.1 A), voltage supply
NE
C Class 2, SELV, PELV, input
120 V … 240 V AC
PS50WE24V 7028789
Output 24 V DC, 95 W (3.9 A), voltage supply
NEC Class 2, SELV, PELV, input
100 V … 120 V/220 V … 240 V AC
PS95WE24V 7028790
15.3 Deflector mirrors
15.3.1 Change in scanning range using deflector mirrors
Overview
T
he information relates to 90° beam deflection per mirror.
Important information
NOTE
T
he use of deflector mirrors reduces the scanning range depending on the number of
deflector mirrors in the protective field.
Table 43: Scanning range with and without 1 or 2 deflector mirrors
Type Scanning range Scanning range with
1 deflector mirror
Scanning range with
2 deflector mirrors
PNS75, PNS125 4 m 3.6 m 3.2 m
15.3.2 PNS75 deflector mirror
Table 44: Ordering information for PNS75 deflector mirror
Mirror height in mm Max. protective field
hei
ght in mm
Type codes Part number
340 300 PNS75-034 1019414
490 450 PNS75-049 1019415
640 600 PNS75-064 1019416
790 750 PNS75-079 1019417
940 900 PNS75-094 1019418
1090 1050 PNS75-109 1019419
1240 1200 PNS75-124 1019420
Using deflector mirrors reduces the effective scanning range.
15 ACCESSORIES
104
O P E R A T I N G I N S T R U C T I O N S | miniTwin4 8012624/10OM/2018-08-09 | SICK
Subject to change without notice
