SICK miniTwin4 User Manual

7 Configuration
7.1 Factory settings
Overview
T
he configurable functions have the following status when delivered:
Table 8: Configurable functions when delivered
Function Configuration when delivered
Beam coding Code 1
Restart interlock Not configured
External device monitoring (EDM) Not configured
Cascading Depending on the order, single system or cas‐
c
ade
To use the functions, you must configure the required functions.
Important information
CAUTION
Im
paired protective function
Changes to the device’s configuration may impair the protective function.
b
The effectiveness of the protective device must be checked after any change to
the configuration.
b
The person carrying out the change is also responsible for maintaining the protec‐
tive function of the device.
Further topics
•
"T
esting plan", page 40
7.1.1 Changing the configuration later
Overview
If a pr
e-configured safety light curtain is to be installed and wired in its future environ‐
ment, the safety light curtain can be reset to its factory settings and re-configured in
one single procedure.
Further topics
•
"Indications when switching on", page 83
7.2 Configuring beam coding
Overview
Be
am coding is always automatic. In the event of an optical fault caused by an adjacent
system, the system experiences a fault (see fault display). After the next power-up, the
code is automatically set to code 2.
In a cascade system, the codes are automatically set to code 1 or code 2 in alternation.
CONFIGURATION 7
8012624/10OM/2018-08-09 | SICK O P E R A T I N G I N S T R U C T I O N S | miniTwin4
63
Subject to change without notice
