SICK miniTwin4 User Manual

Minimum Typical Maximum
Ambient operating temperature (UL/
C
SA: surrounding air temperature)
-20 °C +55 °C
Air humidity (non-condensing) 15% 95%
Storage temperature -25 °C +70 °C
Housing cross-section 15 mm × 24 mm
Dimensions including male connec‐
t
or
15 mm × 32 mm
Vibration resistance 5 g, 10–55 Hz (EN 60068-2-6)
Shock resistance 10 g/16 ms (EN 60068-2-27)
Housing, materials
T
able 19: Housing, materials
Material
Dimensions Depending on type
Housing AlMgSi 0,5 (ENAWL6060 T6)
Front screen PC
Bracket Polyamide PA 66 GF30
End cap Polyamide PA 66 GF30
Printed circuit boards Glass fiber reinforced epoxy resin with flame retardant
TBBPA
System connection
External material of the cable TPU (PUR)
Packaging Corrugated cardboard with polyethylene
Further topics
•
"Table of weights", page 92
•
"Accessories", page 101
•
"Dimensional drawings", page 94
13.2 Response time
Overview
T
he response time depends on the following parameters:
•
Resolution
•
Protective field height
•
Beam coding
•
Number of cascaded devices
Response time for a single device
Table 20: Response time for a single device
Minimum Typical Maximum
Response time of single device with
14 mm r
esolution (protective field
height 120 to 720 mm)
≤ 14 ms
Response time of single device with
14 mm resolution (protective field
height 780 to 1,200 mm)
≤ 17 ms
TECHNICAL DATA 13
8012624/10OM/2018-08-09 | SICK O P E R A T I N G I N S T R U C T I O N S | miniTwin4
91
Subject to change without notice
