SICK OD2000 User Manual

3 Product description
3.1 Scope of delivery
Table 2: Scope of delivery
No. of
units
Component Note
1 Device in the version ordered Depending on version
1 Printed safety notes, multilin‐
gual
Brief information and general safety notes
The actual scope of delivery may differ for special designs, additional orders or due to
the latest technical changes.
3.2 Product ID
3.2.1 Type label
The type label gives information for identification of the device.
OD2000-2452T15
6 074 383
2035123001F
Input
:
18...24 V DC Class 2
≤ 100mA
4-20mA 0-10V/
1 - L+
3 - M
4 - Q1/C
2 - Q2/Q
A
5 - In1
:
:
:
:
:
:
:
Qout
Q
A
out
BN
BU
BK
WH
GY
SICK AG
OD2000
D-79183 Waldkirch, Germany
DID
8389222
www.sick.com/8026231
1
3
2
4
7
9
5
6
8
ß
à
á
á
25
Figure 3: Type label OD2000 (example, device type laser class 2)
1
Device family
2
Data Matrix code with product data and link to product page
3
Approval marks and test symbols
4
Link to the operating instructions
5
IO-Link character and device ID number
6
Place of manufacture
7
Protection class label
8
Pin assignment
9
Electrical data
ß
Serial number
à
Part number
á
Type code
3 PRODUCT DESCRIPTION
12
O P E R A T I N G I N S T R U C T I O N S | OD2000 8026231/1I18/2023-01-05 | SICK
Subject to change without notice
