SICK OD2000 User Manual

10 Technical data
NOTE
The relevant online product page for your product, including technical data, dimensional
drawing, and connection diagrams, can be downloaded, saved, and printed from the
Internet.
The call is made via the SICK Product ID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product, see type label.
{S/N} corresponds to the serial number of the product, see type label (if indicated).
Please note: This documentation may contain further technical data.
10.1 Mechanics/Electronics
Supply voltage U
V
DC 18V ... 24V, ±10%, including residual ripple
1)
Power consumption <1.5W (at 24V DC)
2)
Initialization time Max. 300ms
Warm-up time <30minutes
3)
Housingmaterial Plastic (PBT)
Viewing window mate‐
rial
Plastic (PMMA)
Connection type Cable with male connector, M12, 5-pin, A-coded, 30cm
Tightening torque of
fixing screws
Max. 0.8Nm
Display OLED display, status LEDs
Control elements 4pushbuttons
Weight 90g
Dimensions (W x H x D) 27mm x 60mm x 50mm
Enclosure rating IP67
Protection class III (EN 50178)
Electrical safety IEC 61010-1 AMD 1:2016-12
1)
Limit values, reverse-polarity protected.
2)
Without load, at +20°C.
3)
During the device warm-up phase, the measured values are subject to an increased variance (temperature drift).
TECHNICAL DATA 10
8026231/1I18/2023-01-05 | SICK O P E R A T I N G I N S T R U C T I O N S | OD2000
51
Subject to change without notice
