Table 5: Process data formats
No. Description Comment
Process data structure 1 PDI48.INT32_INT8
Bit 0 = Q1
Bit 1 = Q2
Bit 2…7 = empty
Bit 8…15 = Scale
Bit 16…47 = Distance
Factory setting
Process data structure 2 Bit 0 = Q1
Bit 1 = Q2
Bit 2…15 = empty
Bit 16…47 = Signal level
-
Process data structure 3 Bit 0 = Q1
Bit 1 = Q2
Bit 2…15 = empty
Bit 16…47 = Timer
-
Process data structure 4 Bit 0 = Q1
Bit 1 = Q2
Bit 2…15 = empty
Bit 16…47 = Edge height
-
7.2.2 Device data
Device data (parameters, identification data, and diagnostic information) can be trans‐
mitted to and from the device. A product-specific device description file (IODD file) is
required in the IO-Link master for this purpose.
A download package containing the IODD file and supplementary documentation is
available at www.sick.com/OD2000.
7.3 Operation via SOPAS ET
Version 2021.2 and higher of the SOPAS Engineering Tool (SOPAS ET) software can
be used to parameterization of the device and for service and diagnostic purposes.
Measured values can be visualized and all device functions can be set and checked in
SOPASET. The device immediately applies parameters that have been modified using
SOPASET and permanently saves them. A separate function does not have to be called
up for this purpose.
SOPAS ET is particularly suitable for parameterizing the region of interest (ROI) and
edge height jump functions.
Requirements
■
A computer with the SOPASET software installed on it, and a free USB2.0
compatible port
■
SICK SiLink2 Master (available as accessory)
■
Connection cable with M12 male and female connectors, 5-pin (available as
accessory)
NOTE
The most up-to-date version of the SOPASET software can be downloaded from
www.sick.com/SOPAS_ET. The respective system requirements for installing SOPASET
are also specified there.
Establishing a connection
1. Connect the device to the SiLink2master via the male connector or an additional
connection cable.
7
OPERATION
24
O P E R A T I N G I N S T R U C T I O N S | OD2000 8026231/1I18/2023-01-05 | SICK
Subject to change without notice
