SICK OD2000 User Manual

7.1.3 Main menu
7.1.3.1 Functions in the main menu
Overview of functions
Menu groups
•
Measurement
•
Q1 Output
•
Q2/Qa Output
•
IN Input
•
Device
•
Info
•
Back to Run
Further topics
•
Description of operation (information about the individual menu groups)
•
Menu structure in the main menu
7.1.3.2 Opening main menu
Opening the menu group
1.
To open the main menu, briefly press the pushbutton in RUN mode.
2.
Use the and pushbutton to select a menu group.
3.
Confirm the selection with the pushbutton.
✓
The display shows the corresponding menu group.
7.1.4 Setting parameters
Selecting parameters
1.
Within a menu group, use the and pushbuttons to select the desired
parameter.
2.
Confirm selection with the pushbutton.
Select option
1. Select parameters.
2.
Use the and pushbutton to select the desired option.
3. Perform one of the following steps:
■
To save the setting, press the
pushbutton.
■
To cancel the process, press the
pushbutton.
4.
To return to the measured value display, press the pushbutton until the meas‐
ured value is displayed.
Teaching value
1. Select parameters.
✓
The display shows the current measured value.
2. Align the device at the desired distance.
3.
To teach in the value, press the pushbutton.
✓
The value is set to the current distance at the time the pushbutton is pressed. The
value is taught in.
Adjust the value
1. Select parameters.
✓
The current value of the parameter is displayed. First digit on the left flashing.
2.
Set the flashing digit with the and pushbuttons.
7 OPERATION
22
O P E R A T I N G I N S T R U C T I O N S | OD2000 8026231/1I18/2023-01-05 | SICK
Subject to change without notice
