SICK OD2000 User Manual

OD2000-700xxxx
1 2
1 2
4
4
3
3
1400 (55.12)0
1400 (55.12)0
4 (0.16) 4 (0.16)
14.5 (0.57)
53 (2.09)
53 (2.09)
32 (1.26)
172 (6.77)
10 (0.39)
180 (7.09)
Distance in mm (inch)
Distance in mm (inch)
Dimensions in mm (inch) Dimensions in mm (inch)
Figure 24: Interference range for OD2000-700xxxx, unit for distance values: mm (inch), decimal
separator: period
1
Optical axis sender and receiver
2
Interference range
3
Dimensions in mm (inch)
4
Distance in mm (inch)
10.7 Light spot size
OD2000-030xxxx
Ø 120 µm
0 30 (1.18)25 (0.98)
Ø 50 µm
Ø 150 µm
35 (1.38)
Figure 25: Typical light spot size for OD2000-030xxxx, unit for distance values: mm (inch),
decimal separator: period
10 TECHNICAL DATA
60
O P E R A T I N G I N S T R U C T I O N S | OD2000 8026231/1I18/2023-01-05 | SICK
Subject to change without notice
