SICK OD2000 User Manual

Setting Q1 Timer mode
NOTE
If you are using Timer mode, set a fixed cycle time (not Auto).
Set the Timer setup for at least as long as the cycle time. If you use the Switch-on/off delay
timer mode, set the Timer setup for at least twice as long as the cycle time.
> Q1 output > > Q1 Timer mode > > Select option >
Parameter Value Factory setting
Q1 Timer mode Off
Switch-on delay
Switch-off delay
Switch-on/off delay
Impulse (one shot)
Off
7.4.2.3 Q1/Q2 Hysteresis menu
The hysteresis is the distance difference between the switch-on and switch-off point.
If the measured distance fluctuates around the set switching point, the hysteresis is
necessary for stable switching behavior. To achieve a more precise switching behavior,
set a smaller value for the hysteresis. To achieve more stable switching, set a larger
value for the hysteresis.
Setting Q1 Hysteresis
> Q1 output > > Q1 Hysteresis > > Set value >
Parameter Value Factory setting
Q1 Hysteresis 0mm ... 2,147.48mm OD2000-030: 0.1mm
OD2000-050: 0.2mm
OD2000-245: 0.5mm
OD2000-350: 1mm
OD2000-700: 1.5mm
7.4.3 Q1 Output menu group
The Q1 output is a digital output. In addition, the output serves as a communication
line for bidirectional data transmission when using the IO-Link interface.
The Q1 output offers different output modes. If an output mode is selected, the
required settings can be taught in or set manually. Depending on the selected output
mode, different parameters are available.
7.4.3.1 Setting the switching point
A switching point can be taught-in or set manually.
The SP2 switching point is only available in the window output mode. In the case of a
switching window, do not teach in the same distance value for the near-sensor distance
and the far-sensor distance.
Teaching in the switching point
Set the switching point to the current distance at the time the pushbutton is pressed,
see "Teaching value", page 22.
Teachable parameters
•
Q1 SP1 teach-in (auto)
•
Q1 SP2 teach-in (auto)
OPERATION 7
8026231/1I18/2023-01-05 | SICK O P E R A T I N G I N S T R U C T I O N S | OD2000
31
Subject to change without notice
