SICK OD2000 User Manual

Digital output Number: 2
2)
Type: Push-pull / PNP/NPN, selectable
Max. output current I
A
: ≤100mA
Analog output
3)
Quantity: 1
Type: Current output / voltage output
Function: Selectable
Current: 4mA ... 20mA, ≤300W
Voltage: 0V ... 10V, >10kW
Resolution: 16bit
1)
Can be used as Sender off, trigger for hold functions or deactivated.
2)
PNP/PP: HIGH = U
V
>13.5V / LOW = U
V
<8V.
NPN: HIGH = U
V
<8V / LOW = U
V
>13.5V.
3)
Not available for devices without an analog output, see "Device variants", page 13.
10.5 Ambient data
Ambient operating
temperature
-10°C ... +50°C
1)
Storage temperature -20°C ... +60°C
Relative humidity (non-
condensing)
35% ... 85%
Temperature drift OD2000-030xxxx: 6μm/K
OD2000-050xxxx: 12µm/K
OD2000-130xxxx: 84µm/K
OD2000-245xxxx: 210μm/K
OD2000-350xxxx: 300μm/K
OD2000-700xxxx: 600µm/K
Typical ambient light
immunity
Artificial light: ≤3,000lx
2)
Sunlight: ≤10,000lx
Vibration resistance EN 60068-2-6, EN 60068-2-64
Shock resistance EN 60068-2-27
1)
Operating temperature at U
V
= 24V.
2)
With constant object movement in the measuring range.
10 TECHNICAL DATA
54
O P E R A T I N G I N S T R U C T I O N S | OD2000 8026231/1I18/2023-01-05 | SICK
Subject to change without notice
