Parameter Value Factory setting
Qa 0V teach-in (auto) Setting analog value
OD2000-030:
-5.04mm ... +5.75mm
OD2000-050:
-10.10mm ... +11.50mm
OD2000-245:
-176.75mm ... +189.00mm
OD2000-350:
-252.50mm ... +271.00mm
OD2000-700:
-505.00mm ... +550.00mm
OD2000-030: -5.00mm
OD2000-050: -10.00mm
OD2000-245: -175.00mm
OD2000-350: -250.00mm
OD2000-700: -500.00mm
Qa 0V teach-in (manual)
Qa 10V teach-in (auto) OD2000-030: +5.00mm
OD2000-050: +10.00mm
OD2000-245: +175.00mm
OD2000-350: +250.00mm
OD2000-700: +500.00mm
Qa 10V teach-in (manual)
7.4.4.4 Q2 output mode
Digital output functions can also be set instead of analog output modes. The operation
and setting options are identical to output Q1, see "Q1 Output menu group", page 31.
Additionally, at Q2 the Q2 Q2=Q1 not function is not available (inversion of Q1). With this
function, the inverted switching signal of Q1 is output via Q2. For example, if the High
signal is output at Q1, Low is output via Q2.
Setting digital output
> Q2/Qa Output > > Q2 Mode > > Select output mode (switching) >
7.4.5 IN Input menu group
To use the functions at the IN Input, the input must be active (any setting except Off). The
Off setting deactivates the input and, therefore, all functions.
NOTE
Deactivating the input is possible only via the display, SOPAS ET, or IO-Link, but not via
the input itself.
The behavior of the input can be selected as normally open contact (High-active, factory
setting) or normally closed contact (Low-active). When Sender off is used, the logic also
determines whether the creation of a signal at the input causes the sender to switch off
(factory setting) or on.
7.4.5.1 IN Function menu
Functions
•
Switch the sender on and off at defined times.
•
Activate device functions.
Sender off: The sender is switched off for the duration of the applied signal.
Setting the IN Function
> In1 Input > > IN Function > > Select option >
Parameter Value Factory setting
IN Function Off
Hold
Zero point teach-in
Sender off
Sender off
OPERATION 7
8026231/1I18/2023-01-05 | SICK O P E R A T I N G I N S T R U C T I O N S | OD2000
41
Subject to change without notice
