SICK OD2000 User Manual

Teaching analog value
Set the analog value to the current distance at the time the button is pressed, see
"Teaching value", page 22.
Teachable parameters
•
Qa 4mA teach-in (auto)
•
Qa 20mA teach-in (auto)
•
Qa 0V teach-in (auto)
•
Qa 10V teach-in (auto)
To teach in an analog value, the device must be able to measure. The distance to the
object must not change during teach-in. The object must be in the measuring range.
Setting analog value manually
Set the analog value manually, see "Adjust the value", page 22.
Adjustable parameters
•
Qa 4mA teach-in (manual)
•
Qa 20mA teach-in (manual)
•
Qa 0V teach-in (manual)
•
Qa 10V teach-in (manual)
7.4.4.2 Qa Analog 4mA…20mA menu
Output Q2 is an analog current output. The measured value is output in the form of a
linearly proportional current value.
Selecting output mode and setting parameters
> Q2/Qa output > > Q2 mode > > Qa Analog 4mA…20mA >
> Q2/Qa Output > > Parameter > > Teach-in or set value>
Parameter Value Factory setting
Qa 4mA teach-in (auto) Setting analog value
OD2000-030:
-5.04mm ... +5.75mm
OD2000-050:
-10.10mm ... +11.50mm
OD2000-245:
-176.75mm ... +189.00mm
OD2000-350:
-252.50mm ... +271.00mm
OD2000-700:
-505.00mm ... +550.00mm
OD2000-030: -5.00mm
OD2000-050: -10.00mm
OD2000-245: -175.00mm
OD2000-350: -250.00mm
OD2000-700: -500.00mm
Qa 4mA teach-in (manual)
Qa 20mA teach-in (auto) OD2000-030: +5.00mm
OD2000-050: +10.00mm
OD2000-245: +175.00mm
OD2000-350: +250.00mm
OD2000-700: +500.00mm
Qa 20mA teach-in (manual)
7.4.4.3 Qa Analog 0V…10V menu
Output Q2 is an analog voltage output. The measured value is output in the form of a
linearly proportional voltage value.
Selecting output mode and setting parameters
> Q2/Qa output > > Q2 mode > > Qa Analog 0V…10V >
> Q2/Qa Output > > Parameter > > Teach-in or set value >
7 OPERATION
40
O P E R A T I N G I N S T R U C T I O N S | OD2000 8026231/1I18/2023-01-05 | SICK
Subject to change without notice
