Repeatability
2)

3)

4)
OD2000-030xxxx: 0.1µm
OD2000-050xxxx: 0.2µm
OD2000-130xxxx: 4µm
OD2000-245xxxx: 10µm
OD2000-350xxxx: 20µm
OD2000-700xxxx: 100µm
Linearity
2)

4)

5)
OD2000-030xxxx: ±10µm
OD2000-050xxxx: ±20µm
OD2000-130xxxx: ±140µm
OD2000-245xxxx: ±350μm
OD2000-350xxxx: ±500μm
OD2000-700xxxx: ±1mm (200mm ... 700mm), ±3mm (700mm ... 1,200mm)
Measuring frequency ≤7.5kHz
Output time ≥0.133ms
Response time ≥0.533ms
6)
Light sender Laser, red
Visible red light
Laser class OD2000-030, OD2000-050xxxx, OD2000-130xxxx: Laser class 1 (IEC60825-1:2014,
EN60825-1:2014)
7)
OD2000-245xxxx, OD2000-350xxxx, OD2000-700xxxx: Laser class 2 (IEC60825-1:2014,
EN60825-1:2014)
8)
Complies with 21CFR 1040.10 and 1040.11 except for conformance with IEC 60825-1 Ed. 3, as
described in document Laser Notice No.56 dated 8May2019.
Typical light spot size OD2000-030xxxx: Ø 50µm (30mm)
OD2000-050xxxx: Ø 70µm (50mm)
OD2000-130xxxx: Ø 300μm (130mm)
OD2000-245xxxx: Ø 500µm (245mm)
OD2000-350xxxx: Ø 600µm (350mm)
OD2000-700xxxx: Ø 1mm (700mm)
Additional function Measured value recording functions and evaluation functions, adjustable average filter and median
filter, switching point modes: Single point SP1 (DtO) / window SP1, SP2 (window or ObSB) / teacha‐
ble digital output, invertible digital output, teachable analog output
9)
, invertible analog output
9)
,
switchable analog output (mA/V)
9)
, multifunction input: Sender off/hold functions/deactivated,
switch off display, operating button lock, display can be rotated 180°, alarm function, edge height
jump, timer mode (switch-on and switch-off delay, pulse)
1)
6% ... 90% reflectance; with standard settings.
2)
Measurement to 60% reflectance (ceramic, white).
3)
Average value setting: 512
Median: 31
Measuring frequency: 5kHz
In the middle of the measuring range
For static measurement.
4)
At T = 25°C, under constant general conditions.
5)
Observe min. warm-up time of 30minutes.
6)
Dependent on the set averaging or sensitivity.
7)
Visible, wavelength: 655nm, maximum power: 0.39mW, maximum pulse power: 0.39mW, maximum pulse duration: 5ms.
8)
Visible, wavelength: 655nm, maximum power: 1mW, maximum pulse power: 1mW, maximum pulse duration: 5ms.
9)
Not available for devices without an analog output, see "Device variants", page 13.
10.4 Interfaces
IO-Link IO-Link V1.1
Function: Process data, configuration, diagnostics, data storage
Data transmission rate: 230.4kBit/s (COM3), process data length 6bytes, minimum cycle time
1ms
Digital input In
1

1)
TECHNICAL DATA 10
8026231/1I18/2023-01-05 | SICK O P E R A T I N G I N S T R U C T I O N S | OD2000
53
Subject to change without notice
