3.2.2 Type code
Type code structure
OD2000 – a b c d e f
Place‐
holder
Description Characteristic
a Center of the measuring
range
030: 25mm ... 35mm
050: 40mm ... 60mm
130: 60mm ... 200mm
245: 70mm ... 420mm
350: 100mm ... 600mm
700: 200mm ... 1,200mm
b Laser class 1: Laser class 1
2: Laser class 2
c Light spot geometry T: Dot, round
d Interface 1: Analog I/U
1)
, IO-Link
e Connection type 5: Cable with M12 connection, 5-pin
f Device type “Empty”: Default type
S: Special device
1)
Not available for devices without an analog output, see "Device variants", page 13.
3.3 Device variants
Type Measuring range Interface Connection type
OD2000-030xxxx 25mm…35mm 2 outputs:
1 Digital output with IO-
Link 1.1
1 Analog output or digi‐
tal output (selectable)
1 input:
1 digital input
Cable with male con‐
nector, M12, 5-pin, A-
coded, 30cm
OD2000-050xxxx 40mm…60mm
OD2000-130xxxx 60mm…200mm
OD2000-245xxxx 70mm…420mm
OD2000-350xxxx 100mm…600mm
OD2000-700xxxx 200mm…1,200mm
OD2000-030xxxx
S01
25mm…35mm 2 outputs:
1 Digital output with IO-
Link 1.1
1 Digital output
1 input:
1 digital input
OD2000-050xxxx
S01
40mm…60mm
OD2000-245xxxx
S01
70mm…420mm
OD2000-350xxxx
S01
100mm…600mm
OD2000-700xxxx
S01
200mm…1,200mm
The information about the analog output is not relevant for the OD2000-xxxxxxxS01
devices.
3.4 Principle of operation
3.4.1 Measurement principle
The displacement measurement sensor determines the distance to an object using the
triangulation principle.
PRODUCT DESCRIPTION 3
8026231/1I18/2023-01-05 | SICK O P E R A T I N G I N S T R U C T I O N S | OD2000
13
Subject to change without notice
