SICK OD2000 User Manual

OD2000-700xxxx
Ø 600 µm
0 700 (27.56)200 (7.87)
Ø
1000 µm
Ø
1600 µm
1200 (47.24)
Figure 30: Typical light spot size for OD2000-700xxxx, unit for distance values: mm (inch),
decimal separator: period
10.8 Linearity diagram
OD2000-030xxxx
3
4
5
1
2
25
(0.98)
26
(1.02)
27
(1.06)
28
(1.10)
29
(1.14)
30
(1.18)
31
(1.22)
32
(1.26)
33
(1.30)
34
(1.34)
35
(1.38)
–0.06
(–0.0023)
–0.04
(–
0.0015 )
–0.02
(–
0.0007 )
0.0
0.02
(
0.0007 )
0.04
(
0.0015 )
0.06
(0.0023)
Typical linearity deviation in mm (inch)
Distance in mm (inch)
1
Typical linearity deviation in mm (inch)
2
Distance in mm (inch)
3
White 60% remission factor
4
Black 9.5% remission factor
5
Stainless steel
10 TECHNICAL DATA
62
O P E R A T I N G I N S T R U C T I O N S | OD2000 8026231/1I18/2023-01-05 | SICK
