SICK OD2000 - Interference Range: OD2000-350 xxxx

OD2000-350xxxx
1 2
1 2
4
4
3
3
660 (25.98)0
660 (25.98)0
4 (0.16) 4 (0.16)
14.5 (0.57)
27 (1.06)
27 (1.06)
30 (1.18)
132 (5.20)
10 (0.39)
90 (3.54)
Distance in mm (inch)
Distance in mm (inch)
Dimensions in mm (inch) Dimensions in mm (inch)
Figure 23: Interference range for OD2000-350xxxx, unit for distance values: mm (inch), decimal
separator: period
1
Optical axis sender and receiver
2
Interference range
3
Dimensions in mm (inch)
4
Distance in mm (inch)
