SICK OD2000

OD2000-245xxxx
1 2
1 2
4
4
3
3
460 (18.11)0
460 (18.11)0
4 (0.16) 4 (0.16)
14.5 (0.57)
20 (0.79)
20 (0.79)
28 (1.10)
108 (4.25)
10 (0.39)
60 (2.36)
Distance in mm (inch)
Distance in mm (inch)
Dimensions in mm (inch) Dimensions in mm (inch)
Figure 22: Interference range for OD2000-245xxxx, unit for distance values: mm (inch), decimal
separator: period
1
Optical axis sender and receiver
2
Interference range
3
Dimensions in mm (inch)
4
Distance in mm (inch)
