Function RUN mode starting
point
Description
Display light distribu‐
tion curve
Distance(bar) Display qualitative light intensity distribution on
the receiver element.
The light distribution curve is divided into four
areas on the display. The device automatically
changes to the area where the maximum is
located.
Teach in analog val‐
ues, scale analog
characteristic curve
2)
Analog value Teach in the upper and lower limit values of
the analog characteristic curve. Creates a scal‐
ing of the analog characteristic curve.
Set mode Mode Choose between Precision, Speed and Custom‐
ized modes.
Make suitable default settings depending on
the application.
Recording data Recording
To start recording data, briefly press the
pushbutton. To stop the recording, briefly press
the pushbutton again.
When starting a recording, the previously made
recording is automatically deleted.
Analyze data Recording To display the results of the recording, press
the pushbutton for >3seconds.
1)
SP2 is only available in the output mode window.
2)
The function is only available if the output is set as an analog output in the main menu.
Not available for product types without an analog output, see "Device variants", page 13.
Set mode function
Mode Parameter Factory setting
Precision Cycle time Auto
Average filter 512
Median filter 31
Speed Cycle time 133 μs
Average filter Off
Median filter Off
Customized
1)
Cycle time Auto
Average filter 128
Median filter 31
1)
If you edit parameters manually, the device automatically switches to Customized mode.
If you set the Customized mode, the factory settings will correspond to the delivery state.
Further topics
•
Quick menu structure
7.1.2.2 Opening quick menu
1. Open required display in RUN mode as the starting point.
2.
Press the pushbutton for >3seconds.
✓
The display shows the corresponding function.
OPERATION 7
8026231/1I18/2023-01-05 | SICK O P E R A T I N G I N S T R U C T I O N S | OD2000
21
Subject to change without notice
