Status LEDs
Status LED Status (color) Description
PWR (status indicator)
O (Green)
Voltage supply available, device ready for use
o (Green)
Voltage supply not available
Ö (Green)
Voltage supply available, device ready for use,
connection to an IO-Link master available
Q1 (output display)
O (Orange)
Digital output active
o (Orange)
Digital output not active
Q2/Q
A
(output display)
O (Orange)
Digital output active or measured value within
the scaling range for the analog output
o (Orange)
Digital output not active or measured value
outside the scaling range for the analog output
O = Lights up; Ö = Flashes; o = Does not light up.
Operating pushbuttons
Button Function Description
Open menu, confirm input
•
Starting from RUN mode, open the quick menu or
main menu.
•
Confirm input.
•
Switch to the next menu level of a selected function.
•
Move the cursor to the right when entering numbers.
Cancel
•
In the quick menu: Switch to RUN mode.
•
Switch to the previous menu level.
•
Move the cursor to the left when entering numbers.
Navigating
•
Scroll between several displays of a menu level.
•
Choose between several options.
•
Increase the value of a numeric input.
Navigating
•
Scroll between several displays of a menu level.
•
Choose between several options.
•
Decrease the value of a numeric input.
PRODUCT DESCRIPTION 3
8026231/1I18/2023-01-05 | SICK O P E R A T I N G I N S T R U C T I O N S | OD2000
15
Subject to change without notice
