SICK VMS4100 Operating Instructions

SYSTEM DESCRIPTION 3
37
8023994-17I6/2020-03-19|SICK
Subject to change without notice
ORIGINAL OPERATING INSTRUCTIONS| VMS4100/5100
Measuring range and scale interval value for VMS5100 - Operating condition 4
(“Singulated”, “Touching/Side-by-Side” operating modes)
Min. Max. Scale value (d) Remarks
Length
≥ 100 mm
≥ 4.0"
≤ 5,500 mm
≤ 216.0"
10 mm
0.4"
Longest dimension of
the measuring object
Width
≥ 100 mm
≥ 4.0"
≤ 1,200 mm
≤ 47.0"
10 mm
0.4"
Dimension of the measuring
object orthogonal to the longest
dimension
Height
≥ 50 mm
≥ 2.0"
≤ 1,100 mm
≤ 43.0"
5 mm
0.2"
Maximum height of the
measuring object relative to
the transport belt surface
Tab. 4: Measuring range and scale interval value for VMS5100 (“Singulated”, “Touching/Side-by-
Side” Operating condition 4)
Measuring range and scale interval value for VMS5100 - Operating condition 5
(“Singulated”, “Touching/Side-by-Side” operating modes)
Min. Max. Scale value (d) Remarks
Length
≥ 100 mm
≥ 4.0"
≤ 5,500 mm
≤ 216.0"
10 mm
0.4"
Longest dimension of
the measuring object
Width
≥ 100 mm
≥ 4.0"
≤ 1,200 mm
≤ 47.0"
10 mm
0.4"
Dimension of the measuring
object orthogonal to the longest
dimension
Height
≥ 100 mm
≥ 4.0"
≤ 1,100 mm
≤ 43.0"
10 mm
0.4"
Maximum height of the
measuring object relative to
the transport belt surface
Tab. 5: Measuring range and scale interval value for VMS5100 (“Singulated”, “Touching/Side-by-
Side” Operating condition 5)
Measuring range and scale interval value for VMS5100 - Operating condition 6
(“Singulated”, “Touching/Side-by-Side” operating modes)
Min. Max. Scale value (d) Remarks
Length
≥ 100 mm
≥ 4.0"
≤ 5,500 mm
≤ 216.0"
10 mm
0.4"
Longest dimension of
the measuring object
Width
≥ 50 mm
≥ 2.0"
≤ 1,200 mm
≤ 47.0"
5 mm
0.2"
Dimension of the measuring
object orthogonal to the longest
dimension
Height
≥ 20 mm
≥ 1.0"
≤ 1,100 mm
≤ 43.0"
2 mm
0.1"
Maximum height of the
measuring object relative to
the transport belt surface
Tab. 6: Measuring range and scale interval value for VMS5100 (“Singulated”, “Touching/Side-by-
Side” Operating condition 6)
