Dimensional drawings
C.1 Dimensional drawings of the mounting rails
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
C-5
Mounting rail 530 mm
The figure below shows the dimensional drawing of the 530 mm mounting rail.
0
Figure C-7 Dimensional drawing of the mounting rail with standard width of 530 mm.
Mounting rail 830 mm
The figure below shows the dimensional drawing of the 830 mm mounting rail.
0
Figure C-8 Dimensional drawing of the mounting rail with standard width of 830 mm.
