Fire & Security Products
Siemens Building Technologies Group
05.2003
Determine the alarm organization
the CS1140 fire detection system CS1140 has up to 64 programmable organization
levels (AREAS)
a number of ”Alarm variants” are possible (can be selected per ZONE)
the time countdown memories ”V1” and ”V2” must be specified individually
the time countdown memory ”V2” can be defined per ZONE (if required)
various special local functions are provided
the alarm organization is programmed individually (via maintenance PC)
Organization of system operation
The place of operation of the fire detection system must be determined from an orga-
nizational point of view
If required a second operating facility must be provided
If operating units are particularly exposed, they must be fitted with a lockable plexiglass
door (H26T... + Z3S...)
The type of event and the location are displayed on the operating unit in plain text
The locations (rooms etc.) are individually defined by means of the ”User text” (via
maintenance PC)
If required, an additional event-related instruction, a so-called counter-measures
text, can be allocated
The fire detection system may only be operated by instructed personnel (operating ac-
cess is therefore protected by password or key switch)
Details of control terminal AlgoPilot see page 42
