Siemens Cerberus CS1140 Planning

e4595e6
13
Fire & Security Products
Siemens Building Technologies Group
05.2003
6.3 Meaning of the suffix 41, 42, 43
Indicates the outline quantities (see chapter 7) respectively size of the equipped RAM:
Cx1141 2x256Kx8Bit
Cx1142 2x512Kx8Bit
Cx1143 4x512Kx8Bit
6.4 Hardware
Type of
station
Module
Function
’Main CPU’
Function
’Operation’
Function
’Gateway’
CI1142
AlgoPilot B3Q660/670/680/685

CI1142
AlgoPilot B3Q460/480/485

CC1142
E3X102

CC1142
E3X101

CC1143
E3X103
−
−
CC1143
E3X101 + K3N010
−
CT1142
CA1142
AlgoPilot B3Q660/670/680/685

CT1142
CA1141
AlgoPilot B3Q460/480/485
−

CK1142/43 E3H020
− 
–> Module for ’Asien/Pacific’
CI1143 AlgoPilot B3Q565

CI1142 AlgoPilot B3Q560

CT1143
CA1142
AlgoPilot B3Q565

−
CT1142
CA1141
AlgoPilot B3Q560
−

−
CT1142
AlgoPilot B3Q560
CT1142
CA1141
6.5 Parallel control terminals
In parallel to each standard control terminal (’CT’/’CI’), one parallel control terminal can
be connected.
6.5.1 General features/Restrictions
The parallel operation terminal simulates (mirrors) the standard control terminal it is
connected to (same visibility definitions)
Simultaneous operating on parallel control terminal and respective standard control
terminal possible
Allows configuration of more than 16 control terminals per C-Bus
Serial communication (RS232), i.e. stub line connection only (not fail-safe)
connection is supervised on communication failure (on both side)
recommended modem types: Zyxel xxx. Other modems: to be avaluated locally on a
case-by-case basis
6.5.2 Parallel control terminal ’CA’
Based on same hardware as Standard control terminal. Supported control terminal
types: B3Q460/48./560/660/670/680/685/565
From EP/F, all AlgoRex terminal variants and character sets are supported
Required FW-Variants see page 16
