3 Overview technical data CS1140
Operating voltage 115/230VAC ±15% 50...60Hz
Power consumption 40...220VA (per converter B2F020)
Battery operation in the event of mains failure
– standard operating period
– optional
12...24h
up to 72h (see page 91)
Environmental conditions
Temperature during operation
storage
Humidity
0°C ... +40°C
–20°C ... +60°C
max. 95%, no condensation
complies with class 3K5 according to IEC721-3-3
IP protection category (EN60529 / IEC529)
– Control unit
– remote control console AlgoPilot
IP50 H38 cabinet
IP30 H47/67 cabinet
IP30 H37 cabinet
IP52 H26G220 cabinet
IP40 H28G200 cabinet
Dimensions
– Control unit in cabinet H38...
H47...
H67...
H98...
– separate control terminal in cabinet H26G220
H28G200
H37G...
W= 520mm, H = 602mm, D = 100mm / 155mm
W= 434mm, H = 735mm, D = 300mm
W= 434mm, H = 1130mm, D = 300mm
W= 600mm H = 2110mm D = 300mm
W= 366mm, H = 219mm, D = 76mm
W= 520mm, H = 300mm, D = 70mm
W= 510mm H = 540mm D = 200mm (214mm)
Colour
– control unit cabinets H38... / H47... / H67... / H98...
– operating unit front terminal B3Q...
– control terminal cabinet H26G220
H28G200
H28T...
H37...
RAL7035 light grey
RAL 9006 silver, Pantone 427C, 431C grey
Pantone 421 grey
RAL7035 light grey
1E110 dark grey
RAL7035 light grey
