Siemens Cerberus CS1140 Planning

e4595e24
65
Fire & Security Products
Siemens Building Technologies Group
05.2003
24.7 Detection line ”collective”
All detectors on a line have the same collective address (ZONE)
Line termination depending on application by means of transzorb or EOL22 (Ex)
Number of detectors per line:
DS11 detectors: max. 25
MS6/7/9/24: according to individual load connection factor 1)
Connectable types of detectors see compatibility overview (document e1260)
1
8 Stub lines
DJ1192
DO110x
DT110x
F716
F910
ÖÖÖ
AT50 ATAN50
DM110x
DM110x
SB3
24VDC
2
3
8
ÖÖ
ÖÖ
mixed detector series
4
SB2
5
1) for details see document e825 for MS6/7/9
e1508 for DS11 collective
for details see document e1204
’new’ detector series
(DS11, MS9, MS716)
line termination : Transzorb 20V
line resistance : max.150Ω
’old’ detector series
(MS712, MS6)
line termination EOL22
line resistance : max.250Ω
’old’ detector series
DC1192
Ex
DO1101–Ex
DT1101–Ex
Ex
DO1101–Ex
DT1101–Ex
DO110x
No detectors permissible
DF1101–Ex
DF1101–Ex
Line termination
EOL22 (Ex)
Restriction:
only with E3X100 permissible
see document e1204 and UP e109
Line termination
EOL22 (Ex)
R970
E3M080
DT110x
DO110x
ÂÂ
ÂÂ
DLR11..
DLO1191
DF1191/92
DM110x
DBZ1197A
