Structure and function of the FT2080
3
21
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
Button 'Function'
Symbol Designation
<Topology> l Open topology tree
'Element search' l Open element search
'Change language' l Switch between 2 languages
'Print event list' l Print displayed event list from 'main dialog'
'Jump to list entry'
l Open a selected entry by entering a number in the
event list
'Favorites' l Display list of favorites
'Help' l Display general help text
The selection and order of the buttons can be configured. Up to 6 buttons can be
displayed on the GTB.
If the current 'Access level' is less than or equal to the default 'Access level', the
display toggles to the PIN entry dialog window when the following buttons are
pressed:
l 'Main menu',
l 'Topology',
l 'Change language',
l 'Print event list'.
The default 'Access level' is usually 1.
