Structure and function of the FT2080
3
37
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
3.3.2.5 List navigation bar (LNB)
2
1
List navigation bar (LNB)
1 List event 4 'Page up' button
2 List navigation bar 5 Scrollbar
3 System tabs 6 'Page down' button
The list navigation bar (LNB) is used to scroll within an event list. The 'Page up'
and 'Page down' buttons are used for navigation purposes and the scrollbar shows
the ratio of the section of the list displayed to the entire list. The buttons can be
used as soon as the list contains 10 or more entries. If the last alarm is displayed
underneath the event list, the LNB can be used once the list contains 9 or more
entries.
