Structure and function of the FT2080
36
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
3.3.2.4 List event (LE)
List event (LE)
1 'Processing state' symbol 6 List event 2
2 Element text 7 List event 3
3 List event 1 8 Customer text
4 Event text 9 Event symbol
5 List entry number
The list events (LE) indicate the properties of events from a selected event list in
the form of text and symbols. A highlighted list event is displayed as a single event.
Additional symbols are displayed on the right of the event symbols. You will find
more information on additional symbols in chapter 'System tabs (ST) [➙ 24]'.
Up to 9 list events are displayed in the event list one after the other. If the last
alarm (LA) indicator is active, up to 8 list events are visible.
List entries with the state 'unreliable' are identified by '?'
symbol:
The 'unreliable' state can arise due to a network failure, for example.
See also
2 Single event (SE) [➙ 32]
