Structure and function of the FT2080

Touch screen

Building Technologies A6V10380629_en--_a

Fire Safety 2015-09-10

Filter bar

1 'Select station' 3 'Select date/time range'

2 'Select event category' 'Select element'

The current filter settings in the filter bar are displayed in white text. When the filter

bar is open, you cannot access the buttons on the dialog window toolbar, since the

history list is not visible.

Button Function

Open filter

and

Switch between pages

Filter setting selected at the time of

opening

Entry in the local 'Station'

List entry for a faulty 'Stations'

and

Set date and time

Filter buttons in the event memory dialog window

'Select station' filter

1 Element text 4 'Page right' button

2 Customer text 5 'Page left' button

3 Check mark symbol 6 House symbol
