Siemens FT2080 User Manual

Structure and function of the FT2080
3
Touch screen
65
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
Dialog window toolbar
The following table lists the symbols and functions of the buttons on the dialog
window toolbar.
Button 'Function'
Symbol Designation
'Execute
commands'
Open the 'Select command' dialog
window for the highlighted 'Element'
'Show topology'
Show topology for the highlighted
'Element'
'Show Event
memory'
Show progress for the highlighted
'Element'
'Show details'
Show details for the highlighted
'Element'
