3
Structure and function of the FT2080
68
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
The report dialog window displays the following report results: After a report has
been created, this dialog window is displayed for the selected element. The
element data and the report data are sorted by address. Use the buttons on the
dialog window toolbar to execute commands for the entries in the report list.
List entry
List entry in the report dialog window
1 Element symbol 4 List entry number
2 Element text 5 Customer text
3 Report result
Dialog window toolbar
The following table lists the symbols and functions of the buttons on the dialog
window toolbar.
Button 'Function'
Symbol Designation
'Print event list' Print report list
