Structure and function of the FT2080
3
77
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
3.3.5.6 Intervention text dialog window
Intervention text dialog window
The 'Intervention text' displays the intervention text for the highlighted entry. The
intervention text contains information or instructions in relation to the highlighted
entry.
Type of instruction Example
Information No access! Risk of explosion
Instruction
Leave the building following the
designated escape route.
Example intervention text
Use the 'Intervention text' button on the event command bar to call up the
intervention text. The 'Intervention text' button must be configured in
'SintesoWorks'.
