3
Structure and function of the FT2080
76
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
'Customer text' dialog window
'Customer text' dialog window
1 Dialog window title 3 Cursor buttons
2 Input field 4 'Shift key'
Enter a 'Customer text' for the 'Customer text' in the 'Elements' dialog window. Use
the buttons on the keypad.
See also
2 Temporary switching-off [➙ 114]
3.3.5.5 Message display dialog windows
Message display dialog window OK
Message display dialog window not OK
The message display dialog windows show the results of commands that have
been executed. The symbols in the event display are identical to those in the
command execution display.
You must touch the 'Ok' button to close the message display dialog window.
See also
2 Command execution indicator (CEI) [➙ 28]
