8.2 Optional accessories
Power Module PM240-2
112 Hardware Installation Manual, 12/2015, A5E33294624B AD
Braking resistors for PM240-2, 200 V
Table 8- 6 Technical data
Article No.
Re-
sistance
Maximum
power, P
max
Connection
Degree of
protection
Power Module
Rated power
Pdb
Weight
Article Nos.
Frame
size
JJY:023146720008 200 Ω
0.75 kW
Connecting cable
integrated in the
braking resistor
IP20
6SL3210-1PB13-0❒L0
6SL321❒-1PB13-8❒L0
FSA
37.5 W
1.5
JJY:023151720007 68 Ω 2.2 kW IP20 6SL3210-1PB15-5❒L0
6SL3210-1PB17-4❒L0
6SL321❒-1PB21-0❒L0
FSB
110 W 1.8
JJY:02 3163720018 37 Ω
4 kW
IP20
6SL3210-1PB21-4❒L0
6SL321❒-1PB21-8❒L0
FSC
200 W
2.7
JJY:023433720001 20 Ω
7.5 kW
IP20
6SL3210-1PC22-2❒L0
6SL3210-1PC22-8❒L0
FSC
375 W
6.2
JJY:023422620002 7.5 Ω
18.5 kW
10 mm
2
/ 0.5 Nm
8 AWG / 4.5 lbf in
IP21
6SL3210-1PC24-2❒L0
6SL3210-1PC25-4❒L0
6SL3210-1PC26-8❒L0
FSD
930 W 7.0 kg
JJY:023423320001 4.5 Ω
30 kW
16 mm
2
/ 1.2 Nm
6 AWG / 10.6 lbf in
IP21
6SL3210-1PC28-8❒L0
6SL3210-1PC31-1❒L0
FSE
1500 W
8.5 kg
JJY:023434020003 2.5 Ω
55 kW
16 mm
2
/ 1.2 Nm
6 AWG / 10.6 lbf in
IP21
6SL3210-1PC31-3❒L0
6SL3210-1PC31-6❒L0
6SL3210-1PC31-8❒L0
FSF
2750 W 13.5 kg
