Braking resistors for PM240-2, 400 V
Table 8- 7 Technical data
Article number
Re-
sistance
Maximum
power, P
max
Connection
R1 / R2
Degree of
protection
Power Module
Rated power
Pdb
Weight
Article Nos.
Frame
size
6SL3201-0BE14-3AA0 370 Ω
1.5 kW
2.5 mm
2
/ 0.5 Nm
14 AWG / 4.5 lbf in
IP20
6SL3210-1PE11-8❒L1
6SL3210-1PE12-3❒L1
6SL3210-1PE13-2❒L1
6SL3210-1PE14-3❒L1
FSA
75 W 1.5 kg
6SL3201-0BE21-0AA0 140 Ω
4 kW
2.5 mm
2
/ 0.5 Nm
14 AWG / 4.5 lbf in
IP20
6SL321❒-1PE16-1❒L1
6SL321❒-1PE18-0❒L1
FSA
200 W
1.8 kg
6SL3201-0BE21-8AA0 75 Ω
7.5 kW
4 mm
2
/ 0.7 Nm
10 AWG / 6.2 lbf in
IP20
6SL3210-1PE21-1❒L0
6SL3210-1PE21-4❒L0
6SL321❒-1PE21-8❒L0
FSB
375 W 2.7 kg
6SL3201-0BE23-8AA0 30 Ω
18.5 kW
4 mm
2
/ 0.7 Nm
10 AWG / 6.2 lbf in
IP20
6SL3210-1PE22-7❒L0
6SL321❒-1PE23-3❒L0
FSC
925 W
6.2 kg
JJY:023422620001 25 Ω
22 kW
10 mm
2
/ 0.8 Nm
8 AWG / 7.1 lbf in
IP21
6SL3210-1PE23-8❒L0
6SL3210-1PE24-5❒L0
FSD
1100 W
7.0 kg
JJY:023424020001 15 Ω
37 kW
10 mm
2
/ 0.8 Nm
8 AWG / 7.1 lbf in
IP21
6SL3210-1PE26-0❒L0
6SL3210-1PE27-5❒L0
FSD
1850 W
9.5 kg
JJY:023434020001 10 Ω
55 kW
16 mm
2
/ 1.2 Nm
6 AWG / 4.5 lbf in
IP21
6SL3210-1PE28-8❒L0
6SL3210-1PE31-1❒L0
FSE
2750 W
13.5 kg
JJY:023454020001
(JJY:023422620001 ∥
JJY:023434020001)
7.1 Ω
77 kW
10 mm
2
/ 0.8 Nm
8 AWG / 7.1 lbf in
16 mm
2
/ 1.2 Nm
6 AWG / 4.5 lbf in
IP21 6SL3210-1PE31-5❒L0
6SL3210-1PE31-8❒L0
FSF
3850 W 20.5 kg
JJY:023464020001
(JJY:023434020001 ∥
JJY:023434020001)
5 Ω
110 kW
16 mm
2
/ 1.2 Nm
6 AWG / 4.5 lbf in
16 mm
2
/ 1.2 Nm
6 AWG / 4.5 lbf in
IP21
6SL3210-1PE32-1❒L0
6SL3210-1PE32-5❒ L0
FSF
5500 W 27 kg
