Siemens PM240-2

Technical data
7.3 Technical data, 200 V inverters
Power Module PM240-2
72 Hardware Installation Manual, 12/2015, A5E33294624B AD
Table 7- 3 PM240-2, PT, frame sizes A, 1 AC / 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3211…
6SL3211…
…1PB13-8UL0
…1PB13-8AL0
LO base load power
LO base load input current 1 AC
LO base load input current 3 AC
LO base load output current
0.75 kW
9.6 A
5.5 A
4.2 A
HO base load power
HO base load input current 1 AC
HO base load input current 3 AC
HO base load output current
0.55 kW
8.4 A
4.2 A
3.2 A
Fuse according to IEC
Fuse according to UL
3NA3 805 (16 A)
15 A Class J
Power losses without filter
Power losses with filter
0.04 kW
0.04 kW
Required cooling air flow
5 l/s
Weight without filter
Weight with filter
1.8 kg
2.0 kg
Table 7- 4 PM240-2, IP20, frame sizes B, 1 AC / 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3210…
6SL3210…
…1PB15-5UL0
…1PB15-5AL0
…1PB17-4UL0
…1PB17-4AL0
…1PB21-0UL0
…1PB21-0AL0
LO base load power
LO base load input current 1 AC
LO base load input current 3 AC
LO base load output current
1.1 kW
13.5 A
7.8 A
6 A
1.5 kW
18.1 A
9.7 A
7.4 A
2.2 kW
24.0 A
13.6 A
10.4 A
HO base load power
HO base load input current 1 AC
HO base load input current 3 AC
HO base load output current
0.75 kW
11.8 A
5.5 A
4.2 A
1.1 kW
15.8 A
7.8 A
6 A
1.5 kW
20.9 A
9.7 A
7.4 A
Fuse according to IEC
Fuse according to UL
3NE 1814-0 (20 A)
35 A Class J
3NE 1815-0 (25 A)
35 A Class J
3NE 1803-0 (35 A)
35 A Class J
Power losses without filter
Power losses with filter
0.05 kW
0.05 kW
0.07 kW
0.07 kW
0.12 kW
0.12 kW
Required cooling air flow
9.2 l/s
9.2 l/s
9.2 l/s
Weight without filter
Weight with filter
2.8 kg
3.1 kg
2.8 kg
3.1 kg
2.8 kg
3.1 kg
