Siemens PM240-2

Technical data
7.3 Technical data, 200 V inverters
Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
73
Table 7- 5 PM240-2, PT, frame sizes B, 1 AC / 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3211…
6SL3211…
…1PB21-0UL0
…-1PB21-0AL0
LO base load power
LO base load input current 1 AC
LO base load input current 3 AC
LO base load output current
2.2 kW
24.0 A
13.6 A
10.4 A
HO base load power
HO base load input current 1 AC
HO base load input current 3 AC
HO base load output current
1.5 kW
20.9 A
9.7 A
7.4 A
Fuse according to IEC
Fuse according to UL
3NE 1803-0 (35 A)
35 A Class J
Power losses without filter
Power losses with filter
0.12 kW
1)
0.12 kW
1)
Required cooling air flow
9.2 l/s
Weight without filter
Weight with filter
3.4 kg
3.7 kg
1) approx. 0.08 through the heatsink
Table 7- 6 PM240-2, IP 20, frame sizes C, 1 AC / 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3210…
6SL3210…
...1PB21-4UL0
…1PB21-4AL0
…1PB21-8UL0
...1PB21-8AL0
LO base load power
LO base load input current 1 AC
LO base load input current 3 AC
LO base load output current
3 kW
35.9 A
17.7 A
13.6 A
4 kW
43.0 A
22.8 A
17.5 A
HO base load power
HO base load input current 1 AC
HO base load input current 3 AC
HO base load output current
2.2 kW
31.3 A
13.6 A
10.4 A
3 kW
37.5 A
17.7 A
13.6 A
Fuse according to IEC
Fuse according to UL
3NE 1817-0 (50 A)
50 A Class J
3NE 1818-0 (63 A)
50 A Class J
Power losses without filter
Power losses with filter
0.14 kW
0.14 kW
0.18 kW
0.18 kW
Required cooling air flow
18.5 l/s
18.5 l/s
Weight without filter
Weight with filter
5.0 kg
5.2 kg
5.0 kg
5.2 kg
