Siemens PM240-2

Technical data
7.3 Technical data, 200 V inverters
Power Module PM240-2
74 Hardware Installation Manual, 12/2015, A5E33294624B AD
Table 7- 7 PM240-2, PT, frame sizes C, 1 AC / 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3211…
6SL3211…
...1PB21-8UL0
…1PB21-8AL0
LO base load power
LO base load input current 1 AC
LO base load input current 3 AC
LO base load output current
4 kW
43.0 A
22.8 A
17.5 A
HO base load power
HO base load input current 1 AC
HO base load input current 3 AC
HO base load output current
3 kW
37.5 A
17.7 A
13.6 A
Fuse according to IEC
Fuse according to UL
3NE 1818-0 (63 A)
50 A Class J
Power losses without filter
Power losses with filter
0.18 kW
1)
0.18 kW
1)
Required cooling air flow
18.5 l/s
Weight without filter
Weight with filter
5.9 kg
6.2 kg
1) approx. 0.09 through the heatsink
Table 7- 8 PM240-2, IP 20, frame sizes C, 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3210…
6SL3210…
...1PC22-2UL0
…1PC22-2AL0
…1PC22-8UL0
...1PC22-8AL0
LO base load power
LO base load input current
LO base load output current
5.5 kW
28.6 A
22.0 A
7.5 kW
36.4 A
28.0 A
HO base load power
HO base load input current
HO base load output current
4 kW
22.8 A
17.5 A
5.5 kW
28.6 A
22.0 A
Fuse according to IEC
Fuse according to UL
3NE 1802-0 (40 A)
50 A Class J
3NE 1817-0 (50 A)
50 A Class J
Power losses without filter
Power losses with filter
0.2 kW
0.2 kW
0.26 kW
0.26 kW
Required cooling air flow
18.5 l/s
18.5 l/s
Weight without filter
Weight with filter
5.0 kg
5.2 kg
5.0 kg
5.2 kg
